Acuity Brands *281L52, eldoLED OTi100W, 120-277V Input, 100W, 600mA-1250mA Output Max, 0-10V Dimming + Astro Dim, IP66, Programmed using FieldSET Programmer Tool

In stock
SKU: *281L52
$90.72
Rated voltage
Power
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.

Use this text to encourage communication or promote sharing on social networks.

You can also add links

The FieldSET OTi100W is an efficient, dimmable, linear LED driver for outdoor applications.This programmable driver is compatible with the FieldSET LED Driver Programming Tool which provides visual and audible feedback programming. The FieldSET OTi100W is designed for in-field programming and replacement.

Driver Overview

  • Intended for use in LED fixtures including Industrial, High-bay,
  • Outdoor, and Cobra-head fixtures.
  • 100W Output
  • 0-10V Dimming with 5% Minimum Dim Level
  • IP66 Rated
Stock Code
*281L52
Family
eldoLED Optotronic Intelligent Driver | FieldSET
Part No FIELDSET OTI 100W UNV 1250C 2DIM P6 FS J20
Ballast Type
Constant Current
Dimmable Yes
Dimensions Length   6.61" (168mm)
Width    2.36" (59.9mm)
Height   1.5" (38.1mm)
Input
Voltage: 120-277Vac
Current: 0.95A@120V, 0.40A@277V
Output
Voltage: 30-100VDC
Current: 600-1250mA; 700mA default
Power: 100W Max
Bulb Type LED
IP Rating IP66
Mounting Mounting Length 6.0" (152.4mm), Mounting Slot Width 0.28" (7mm)
Operates Intended for use in LED fixtures including Industrial, High-bay, Outdoor, and Cobra-head fixtures.
Power Factor >0.95%
Start Temperature -40ºC-55ºC
UL Listed ULus, CSA, FCC Part 15 Class A
Cross Refefence This item was auto-converted from FIELDSET OTI 100W UNV 1250C 2DIM P6 FS
Memo We provide free programming services for all programmable LED Drivers we sold as per your requested output Current and Voltage. Please leave a detailing memo if you need this service when you check out.
