Allanson ALBRSS1648-26L, RSS Series Magnetic Sign Ballast, For use with T12 HO, T8 HO, and Slimline Lamps 120 Volts, 50/60Hz, 2 to 6 Lamps

In stock
SKU: RSS1648-26L
$350.39
Rated voltage
No. of Lamps

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Allanson RSS Fluorescent Sign Ballasts, 120V Input, 2 to 6 Lamp operation with total lamp footage of 8' minimum and 18' maximum for T8HO or 8' minimum and 24' maximum for T12HO, Rapid Start Ballast.
For 800mA T12/HO Lamps
  For 800mA T8/HO Lamps
No. of Lamps
2 to 6
2 to 6
Lamp Circuits
Circuit I (lamps 1,2,3)
Circuit II (lamps 4,5,6)
Circuit I (lamps 1,2,3)
Circuit II (lamps 4,5,6)
Footage
8ft to 24ft
 8ft to 18ft
Input Voltage
120V
 120V
Max Input Amps
3.85A
 3.82A
Max Input Watts
430W
435W
Open Circuit Voltage
950V
950V
Wiring  Diagram
6-10
6-10
