Alltemp 24-ICM1502, Oil Primary Control, Intermittent Ignition, 30 Seconds Safety Timing
Regular price
$222.99
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Features - Intermittent Ignition
• Controls oil burner, oil valve (if desired) and the ignition transformer
in response to a call for heat .
• Solid state flame sensing circuit .
• LED on terminal strip indicates system lockout.
• Enclosed safety switch with external reset button.
• Mounts on standard 4" x 4" junction box; select models may be
mounted directly on burner housing.
• 69-45610 Cadmium Sulfide Flame Detector and 24 VAC thermostat
required.
• Direct replacement for popular competitive models.
• Controls oil burner, oil valve (if desired) and the ignition transformer
in response to a call for heat .
• Solid state flame sensing circuit .
• LED on terminal strip indicates system lockout.
• Enclosed safety switch with external reset button.
• Mounts on standard 4" x 4" junction box; select models may be
mounted directly on burner housing.
• 69-45610 Cadmium Sulfide Flame Detector and 24 VAC thermostat
required.
• Direct replacement for popular competitive models.
| Ignition Type | Intermittent |
| Safety Timing | 30 seconds |
| Mounting Bracket | For mounting on a standard 4" × 4" junction box or direct mounting on burner housing. |
| Electrical Rating |
Contacts (full load):7.4 A @ 120 VAC; 3.7 A @ 240 VAC
Contacts (locked rotor):44.4 A @ 120 VAC; 22.2 A @ 240 VAC
|
| Temperature Range | -30°F to +130°F |
| Replaces | Honeywell: R8184G4074, R8184G1179, R8184G1302, R8184G4033 |
