Alltemp PSP72KA, Ditek Single Phase Surge Protector, Split (2W+G), 120/240VAC, Surge Current Rating 50000A, Short Circuit Current Rating 10000A
Regular price
$152.32
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The PSP72KA Surge Protective Device provides durable, cost-effective protection and is suitable for use in a variety of locations. This compact, parallel-mount SPD is suitable for 120/240V systems, and is an excellent choice for effective, performance driven surge protection.
- Weatherproof enclosure
- Parallel connection for easy installation
- Diagnostic LED provides positive indication of power, ground presence, and surge protection
- Automatically resets to handle multiple surge events
- Typical Applications A/C disconnect, small electrical panels, pool/well pumps
- Half the response time as similar models
- NEMA 4 rated on the housing
| Service Wiring | Split (2W+G), 120/240VAC |
| Surge Current Rating | 50,000A |
| MCOV | 150/320V |
| Voltage Protection Rating | 700V L-G, 1,200V L-L |
| Short Circuit Current Rating | 10,000A |
| Nominal Discharge Current Rating | 10,000A |
| Certifications | cULus |
