ERP Power ESPT050W-1050-42-Z1, Constant Current LED Driver, Output 44.1W 1050mA 24-42Vdc, Tri-Mode Dimming, IP66 Thermally Enhanced Plastic Case, Input 120-277Vac
Regular price
$53.99
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Stock Code | ESPT050W-1050-42-Z1 |
| Family | ESPT Series 40 to 60 W Constant Current LED Drivers with Tri-Mode Dimming™ (TRIAC, ELV & 0-10 V) |
| Ballast Type | Electronic LED Driver |
| Dimmable | Yes |
| Length | 3.43'' |
| Width | 2.36'' |
| Height | 1.18'' |
| Input Voltage | 120-277Vac |
| Bulb Type | LED |
| Housing | Thermally Enhanced Plastic Case |
| IP Rating | IP66 |
| Mounting | The ESPT driver case must be mounted by using a minimum of two metal clips. By default, the ESPT driver is shipped with 2 metal clips. |
| Output Voltage | 24-42Vdc |
| Output Current | 1050mA |
| Output Power | 44.1W |
| Power Factor | >0.9 |
| Start Temperature | -30°C~70°C |
| Weight | 222 g (7.8 oz) |
| Energy Star | Yes |
| UL Listed | cRUus, CE, FCC |
| Notes | ESPT models with the “-Z1” suffix exhibit a non-linear 0-10V dimming profile with dim-to-off: 10V to 8.1V=100%, 1V to 0.8V=1%, <0.8V dim-to-off. |
| Cross Refefence | Additional metal clips can be ordered with the following part numbers: • ESPT-CLIPS-100: bag of 100 clips • ESPT-CLIPS-1k: bag of 1000 clips |
