Home » ERP Power PKM30W-1050-55-SN, Programmable Constant Current LED Driver, Output 30W 275-1050mA 10-55Vdc, 0-10V Dimming, IP20 Metal Case, Bottom Leads with Studs, Input 120-277Vac
ERP Power

ERP Power PKM30W-1050-55-SN, Programmable Constant Current LED Driver, Output 30W 275-1050mA 10-55Vdc, 0-10V Dimming, IP20 Metal Case, Bottom Leads with Studs, Input 120-277Vac

In stock
SKU: PKM30W-1050-55-SN
$37.99
Rated voltage
Power

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Stock Code PKM30W-1050-55-SN
Family PKM Series 50 & 30 W Programmable Constant Current Class 2 LED Driver with 0-10 V Dimming
Ballast Type Electronic LED Driver
Dimmable Yes
Length  4.20''
Width 2.37''
Height 0.99''
Input Voltage 120-277Vac
Bulb Type LED
Housing Metal Case, Bottom Wire Leads with Mounting Stud
IP Rating IP20
Operates Factory default output current is 700mA
Output Voltage 10-55Vdc
Output Current 0.275 - 1.05A
Output Power 30W
Power Factor >0.9
Start Temperature -30°C~70°C
Weight 252 g (8.9 oz)
Energy Star Yes
UL Listed cRUus, CE, FCC
