Home » IMO LPS-1-040-24DC, LPS Series Single Phase DIN Rail Power Supply, 85-264VAC / 120-370VDC Universal Input, 40W 24VDC 1.7A Output, Plastic Body
IMO

IMO LPS-1-040-24DC, LPS Series Single Phase DIN Rail Power Supply, 85-264VAC / 120-370VDC Universal Input, 40W 24VDC 1.7A Output, Plastic Body

In stock
SKU: LPS-1-040-24DC
$139.77
Output current, power
Rated voltage
Phase

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Input Voltage
 85-264VAC / 120-370VDC
Output Wattage
 40W
Output Voltage
 24VDC
Output Current
 1.7A
Efficiency
 88%
Isolation Voltage
 3000VAC/4242VDC
Isolation Resistance
 100MΩ @ 500VDC
Protection Rated IP20
Case Material Plastic
Dimensions 92 x 41 x 100mm
Cooling Free air convection
Relative Humidity
 20 to 95% RH
Ambient Temperature
 -30°C to +70°C (refer to derating curve)
Derating (50°C to 70°C)  2.5%/°C
Storage Temperature
 -40°C to +85°C
Certifications CE, cULus
Warranty 3-Year
