Intermatic K171H, Locking Type Receptacle, 7-Pin, C136.41 Compliant, 12" lead
Regular price
$49.52
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The K171H provides a receptacle for Locking Type photocontrols with dimming capabilities. The connector interface has a 3-prong power connection that is backward compatible with standard photocontrol units. Also, it offers four contact pads per ANSI C136.41 for dimming and additional control or sensor input.
- NEMA receptacle with 3-prong power sockets.
- Two gold plated contact pads for dimming control signals.
- Two gold plated contact pads for extra control or sensor input signals.
- Integrated sealing gasket.
-
Compliant to ANSI C136.41 specifications.
| Model Number | K171H |
| Description | Locking Type Receptacle, 7-Pin, C136.41 Compliant, 12" lead |
| Color | Black |
| Base Material | UV Stabilized Polycarbonate (UL94-5 VA) |
| Power Contacts Material | Brass/Phosphor Bronze |
| Gasket | (Integrated) Thermal Elastomer |
| Signal Contacts Material | Nickel/Gold Plated Bronze |
| Power Contacts Rating | 480 V max, 15 A max |
| Signal Contacts Rating | 30 VDC, 0.25 A max |
| Temperature (operation) | -40 °F to 158 °F / (-40 °C to 70 °C) |
| UL Certification | cRUus |
| RoHS Certification | N/A |
| Warranty Period | 1-Year limited |
