Intermatic UWZ48E-24U, AC Hour Meter, 24 VAC
Regular price
$94.18
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Flush mounted with bracket, the UWZ48E unit fits into a 1.79" x 1.79" (45.5 x 45.5 mm) cutout. The thickness of the panel for flush mounting can be up to .35" (9 mm). The unit is secured in position by a plastic slip-on retaining bracket. The unit also fits square or round openings for 72 mm with optional 72 mm bezel.
-
Distribution/Control Panel
-
Monitoring
| Model Number | UWZ48E-24U |
| Description | AC Hour Meter |
| Color | Light Gray |
| Mounting Options | Flush |
| Number of Digits (Hours) | 5 |
| Number of Digits (Tenths) | 2 |
| Mounting Description | slip-on retaining bracket |
| Mechanical Movement | Synchronous |
| Maximum Power Consumption (VA) | 1 |
| Wiring Option | 1/4" Spade w/screw clamp |
| Input Voltage Range(s) | 24 VAC, 60 Hz |
| Hz | 60 |
| Temperature (operation) | -40 °F to 160 °F / (-40 °C to 72 °C) |
| UL Certification | RU |
| CSA Certification | cCSAus |
| RoHS Certification | Y |
| Warranty Period | 1-Year limited |
