Intermatic WH2725AT, Pre-Programmed 7-Day Water Heater Timer, Indoor/Outdoor Nema 3R Metal Enclosure, 240 V
Regular price
$322.87
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The WH2725AT pre-programmed 7-day water heater timer features independent 7-day programming for convenient flexibility when load switching differs.
- Program can be repeated on a weekly basis.
- 240 VAC, 60 Hz.
- Lockout feature ensures city code cannot be modified.
- To-the-minute programming for accurate load control and reduced energy costs.
- Relays with Zero-crossing technology to extend the life of the control.
- Automatic Daylight Saving Time (DST) ON/OFF adjustment.
- Temporary override for 1-hour operation.
-
100-hour supercapacitor eliminates battery dependency.
| Model Number | WH2725AT |
| Description | Pre-Programmed 7-Day Water Heater Timer, Indoor/Outdoor Nema 3R Metal Enclosure |
| Color | Gray |
| Minimum ON/OFF Times | 1 min |
| Maximum ON/OFF Times | Indefinite |
| Operation Features | Daylight Saving Time; Holiday |
| Operation Mode | 7 day |
| Backup Restoration Time | 30 Minutes |
| Backup Type | Supercapacitor |
| Backup Protection Time | 100 Hour |
| Mechanism Type | Digital/Electronic |
| Application Compatibilities | LED |
| Enclosure Type | Indoor/outdoor type 3R metal |
| Resistive (NO) Range(s) | 30 A, 240 VAC |
| Inductive Load Ratings NO Ranges | 30 A, 240 VAC |
| Voltage Selection Type | Auto-Voltage |
| Wiring Option | Terminals |
| Input Voltage Range(s) | 240 VAC, 60 Hz |
| Switch Type | DPST |
| Maximum Power Consumption (W) | 5 W |
| Temperature (operation) | -40 °F to 104 °F / (-40 °C to 40 °C) |
| UL Certification | cULus |
| RoHS Certification | N/A |
| Warranty Period | 2-Year limited |
