Klein Tools VDV226-110, Ratcheting Ethernet Cable Crimper / Stripper / Cutter, for Pass-Thru™
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Klein Tools Coax Cable Crimper / Wire Stripper / Wire Cutter is a premium, long lasting tool for CAT3, CAT5e and CAT6/6A cable using RJ11/RJ12 standard and RJ45 Pass-Thru™ connectors. Pass-Thru™ technology significantly reduces prep work time; wiring diagram on the tool helps eliminate rework and wasted materials. Compact, non-slip comfort grip reduces hand strain and stores easily. For use with Klein Pass-Thru™ Connectors (in packs of 10, 50 or 200).
- Modular crimp-connector installation tool for voice and data applications with Pass-Thru RJ45 connector plugs
- Wire stripper, crimper, and cutter all-in-one tool for STP/UTP paired-conductor data cables
- Trims flush to end face of connector eliminating unintended contact between conductors
- Crimps and trims Klein Tools RJ45 Pass-Thru™ Connectors
- Crimps 4, 6 and 8 position modular connectors (RJ11/RJ12 standard and RJ45 Klein Tools Pass-Thru™)
- Full-cycle ratchet mechanism ensures complete connector termination
- On-tool wiring guide helps minimize wiring errors
- Cable parameters: 28-22 AWG flat or round; solid or stranded telephone and data
- Rubber grip for added comfort
- Ratcheting locking mechanism
- Use with Klein Tools Pass-Thru™ Connectors
- Not for use with standard (non Pass-Thru™) connectors
- Replacement blade set available (VDV999-076)
Warnings：Always wear approved eye protection; NOT insulated. Will NOT protect against electrical shock; Never use on or near live electrical circuits; Read carefully and understand instructions before using this tool; Do NOT use the tool to pull the outer jacket off of the cable. Doing so may damage the conductors and the tool.
| Type | Crimper |
| Application | Cable Connection |
| Material | Steel with Black Oxide |
| Handle Color | Yellow/Black |
| Cuts & Strips | Paired Conductor Data Cable (Round STP/UTP); Flat-Satin Phone Cable |
| Cable Type | CAT3, CAT5e, CAT6/6A |
|
Connector Type
|
RJ45 Klein Tools Pass-Thru™, and RJ11, RJ12 Standard |
|
Position/Pair/Conductors
|
4-Position, 1-Pair/2-Conductor, 4-Position, 2-Pair/4-Conductor 6-Position, 2-Pair/4-Conductor, 6-Position, 3-Pair/6-Conductor, 8-Position, 4-Pair/8-Conductor |
|
Overall Length
|
6.094'' (15.5 cm) |
|
Weight
|
14.4 oz (408 g) |
