Leviton OSW12-RMW, Wall Mount Multi-Technology Occupancy Sensor with Isolated Relay, 24 VAC/DC, 1200 Sq.Ft. Coverage, 115 Degree, White
Regular price
$252.35
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Low Voltage Occupancy Sensor lighting control, Wall Mount, Multi-Tech, 1A 30VDC Isolated Relay, 24VAC/VDC, 1200 sq ft, USMCA, Title 24 Compliant.
| Product Type | Occupancy Sensor |
| Sensor Technology | Multi-Technology: Passive Infrared (PIR)/Ultrasonic (US) |
| Sensor Type | Occupancy |
| Relay Type | Isolated Relay |
| Grade | Commercial |
| Time Delay | 30s-30m |
| Coverage (Sq.Ft.) | 1200 Sq. Ft |
| Pattern | 115° |
| Color | White |
| Isolated Relay | 1A @ 30VAC/VDC |
| Voltage | 24 VAC/VDC |
| Power Consumption | 24mA DC, 45mA AC |
| Mounting Type | Wall Mount |
| Mounting Height | 8-10 FT |
| Size | Height 6.43'' (163.32mm), Depth 4.67'' (118.62mm), Sensor Width 2.80'' (71.12mm), Base Width 4.23'' (107.44mm) |
| Application | Cafeterias, Classrooms, Conference rooms, Computer rooms, Day care centers, Workspaces, Offices with cubicles, Partitioned restrooms, Executive, private and open offices |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Relative Humidity | 0% to 95% non-condensing |
| Certifications | UL, Title 24 |
| Warranty | 5-Year Limited |
