Leviton PE500-D0E, 0-10V Reverse Phase Power Extender, Gray
Regular price
$1,289.30
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The Leviton 0-10V Reverse Phase Power Extender (PE500) converts a 0-10V dimming signal to control a fixed line voltage output. One PE500 is used per fixture run up to the maximum wattage of 450W with a 120V load and up to 1,000W on a 277V load. The PE500 mounts directly into a junction box and is plenum rated for easy installation.
| Device Type | Power Extender |
| Sensor Type | Power Pack |
| Color | Gray |
| Voltage | 110-120VAC, 277VAC |
| Frequency | 60Hz |
| Input Current | 3.8A |
| Load Rating | 450W/VA @ 110-120V, 1000W/VA @ 277V |
| Neutral Wire Connection | Required |
