Lovato BFS2523A230, Three-pole Safety Contactor, IEC Operating Current le (AC3) = 25A, AC Coil 50/60Hz, 230VAC, 2NO+3NC Auxiliary Contact

In stock
SKU: BFS2523A230
$193.11
Sale $232.53 $193.11
Rated voltage
Pole
Contact

Use this text to encourage communication or promote sharing on social networks.

You can also add links

230Vac 50-60Hz Control Coil, 3 Pole Safety Contactor, Motor Full Load Amps (FLA, IEC AC3 Rating) Maximum 600V 25A, UL/CSA General Purpose Use (AC1 Rating) 600V 32A, Incorporated Auxiliary Contacts 2NO+3NC, Screw and DIN Rail Mounting

Type of product Safety Contactor
Number of poles 3
Type of coil AC coil 50/60Hz
Rated coil voltage [V] 230
IEC operating current Ith (AC1) [A] 32
IEC operating current and power Ie (AC3) 400V [A/Kw] 25A / 12.5Kw
UL/CSA horsepower ratings 480V [HP] 15
Type of built-in auxiliary contacts 1NC
Type of mounting Screw / DIN rail 35mm
Width (in) 1.77
Height (in) 3.35
Depth (in.) 4.60
Compliance CSA C22.2 n° 60947-1
CSA C22.2 n° 60947-4-1
IEC/EN/BS 60947-1
IEC/EN/BS 60947-4-1
IEC/EN/BS 60947-5-1
UL 60947-1
UL 60947-4-1
Certificates cULus
UL listed for USA and Canada
