Home » Lovato GA032A, Three-Pole Switch Disconnector, Direct Operating Version, 32A, Complete with Black Handle, According to UL60947-4-1
Lovato

Lovato GA032A, Three-Pole Switch Disconnector, Direct Operating Version, 32A, Complete with Black Handle, According to UL60947-4-1

In stock
SKU: GA032A
$81.46
Ampere rating
Pole

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Type of Product Switch disconnectors
Number of Poles 3
Type of Operating Voltage AC
IEC Conventional Free Air Thermal Current Ith [A] 32
UL Standard UL60947-4-1
Type of Installation Screw on plate or 35mm DIN rail
Operating Voltage max [V] 600
Horsepower/FLA Current Three Phase Motor @240V [HP/A] 10/28
Horsepower/FLA Current Three Phase Motor @480V [HP/A]  20/27
Horsepower/FLA Current Three Phase Motor @600V [HP/A] 20/22
Frontal IP Degree IP20
Operating Temperature -25°C - 55°C
HS Code 85365080
Certifications cULus according to UL60947-4-1, CSA C22.2 n°60947-4-1, EAC, KEMA, CCC
Conformity IEC/EN 60947-3
IEC/EN 60947-1
UL60947-4-1
CSA C22.2 n°60947-4-1
