Lovato LVMP30A024, Start-Up Priority Change Relay For 3 or 4 Motors, Modular Version, Auxiliary Supply Voltage 24VAC
Regular price
$360.13
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Type of Product | Start-up priority change relays |
| Functions | Priority change for 3-4 motors |
| Number of Relay Outputs | 4 |
| Rated Supply Voltage | 24VAC |
| Type of Installation | Modular DIN rail mounting |
| Contact Arrangement | 4 NO |
| Rated Operational Voltage AC (IEC) | 250VAC |
| IEC Conventional Free Air Thermal Current Ith | 8A |
| Indication | Display for monitoring motor status, number of starts and working hours |
| Relative Humidity | 20…90% |
| Operating Temperature | -20°C - +55°C |
| Housing Material | polyamide |
| IEC Degree of Protection | IP20 |
| Dimensions (W x H x D) | 72 x 106 x 59.6mm |
| HS Code | 85364900 |
| Certifications | EAC, cULus |
| Compliance |
IEC/EN/BS 61131-2 UL508 CSA C22.2 n°142 |
