Lovato LVMP30A240, Start-Up Priority Change Relay For 3 or 4 Motors, Modular Version, Auxiliary Supply Voltage 100...240VAC
Regular price
$334.93
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Type of Product | Start-up priority change relays |
| Functions | Priority change for 3-4 motors |
| Number of Relay Outputs | 4 |
| Rated Supply Voltage |
100...240VAC
|
| Type of Installation | Modular DIN rail mounting |
| Contact Arrangement | 4 NO |
| Rated Operational Voltage AC (IEC) | 250VAC |
| IEC Conventional Free Air Thermal Current Ith | 8A |
| Indication | Display for monitoring motor status, number of starts and working hours |
| Relative Humidity | 20…90% |
| Operating Temperature | -20°C - +55°C |
| Housing Material | polyamide |
| IEC Degree of Protection | IP20 |
| Dimensions (W x H x D) | 72 x 106 x 59.6mm |
| HS Code | 85364900 |
| Certifications | EAC, cULus |
| Compliance |
IEC/EN/BS 61131-2 UL508 CSA C22.2 n°142 |
