MARCUS AMTH30A6, 30kVA, Commercial Isolation Type, 3 Phase, Primary 600D, Secondary 380Y/220V, Aluminium Winding, Type 3R Enclosure
Regular price
$3,640.00
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Commercial Premium Efficiency Distribution Transformers. Spec No. AMTH30A6. Primary 600V Delta, Secondary 380V Wye / 220V, 30KVA, 60Hz, 3 Phase, Step Down Isolation Type, NEMA 3R Enclosure. Aluminium Conductor. Made in Canada.
| Length (in) | 18.5 (Depth) |
| Width (in) | 22-5/8 |
| Height (in) | 29 |
| Winding Material | Aluminium / Al |
| Phase | Three Phase |
| First Voltage | 600V Delta |
| Secondary Voltage | 380Y / 220V Wye |
| Wattage (w) | 30KVA |
| Efficiency (typical) | 98.40% As per NRCAN 2019 and DOE 2016 |
| IP Rating | Type 3R Enclosure |
| Material | Aluminum Windings |
| Type | Isolation Type |
| Start Temp. (Min) | Temperature Rises: 150°C |
| Start Temp. (Max) | Isulation Class: 220°C |
| Weight (lb.) | 362 Lbs / 164Kgs |
| UL Listed | CSA Certified |
| Warranty | 1-Year |
