Mersen 40351G, Class G Fuse Block, 1-Pole, 480VAC/DC, 30A, Copper Box Connector
Regular price
$56.87
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Mersen Class G fuse blocks accommodate all 15, 20, 30 and 60 ampere Class G fuses. A choice of box, screw or pressure-plate connectors fit a wide range of stranded or solid copper wire. Insulators are glassfilled polycarbonate (GFPC) with verified dielectric strength in excess of 2500V. Fuse blocks feature a unique adder block which can be snapped onto 1-, 2-, or 3-pole blocks to form multi-pole segmented blocks of as many poles as desired. All fuse clips are made of high conductivity tin-plated copper alloy.
| Rated voltage | 480 VAC/DC |
| Frequency (Hz) | 50/60 Hz |
| Ampere Rating | 30 A |
| Fuse Class | Class G |
| Short Circuit Current Rating (SCCR) | 100 kA |
| Number of Poles | 1-Pole |
| Wiring range | Cu #10-14 |
| Fuse Installation Method | Clip-in |
| Torque Rating | 35 lb-in |
| Installation Mounting | Screw Mount or DIN Rail |
| Dimensions | 3.05'' (L) x 0.85'' (W) x 1.45'' (H) |
| Body/Insulating Material | Glass Filled Polycarbonate |
| Safety Certifications | ROHS,UL, CSA |
| Product Weight | 0.15 lb |
