Home » Mersen A099245, High-Speed Cylindrical Fuse, Fast Acting, Size 20x127 gR (gRB), 1500VDC, 5A, CC1500CPgRB20x127/5
Mersen

Mersen A099245, High-Speed Cylindrical Fuse, Fast Acting, Size 20x127 gR (gRB), 1500VDC, 5A, CC1500CPgRB20x127/5

In stock
SKU: A099245
$439.69
Rated voltage
Ampere rating

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Specially developed for DC applications, 20x127 gR cylindrical is a fast acting, full range fuse used in the protection of auxiliaries, control circuit and other measuring and monitoring devices.

Catalogue No FD20GB150V5
Rated Voltage 1500VDC
Ampere Rating 5A
Speed/Characteristic gR
Fuse Size 20x127
Mounting Clip
AC Max I.R./Breaking Capacity: I1 30 kA
Design Details gRB
Connection/Terminal Material Silver-Plated Copper
Connection/Terminal Type Ferrule
Product Diameter 0.81''
Product Length 5''
Body/Insulating Material Ceramic
Product Weight 0.214 lb
Power Dissipation at Rated Current Value 2.3 W
