ORTECH OT-24200-TDWJ, 200W Dimmable Class 2 LED Driver, Input 110-277VAC, Output 24VDC, 8.33 Amps
Regular price
$113.63
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Maximum 200W Class 2 LED driver available with a 24V DC output, designed to provide safe, efficient, and regulated low-voltage power for LED lighting systems while meeting Class 2 safety standards for dependable performance and protection in a wide range of applications.
| Wattage | 200W |
| Input Voltage | 110-277V AC |
| Output Voltage | 24V DC |
| Power Factor | 0.98 at 120V AC | 0.95 at 277V AC |
| Dimmable | Yes |
| Amps | 8.33A |
| Frequency Range | 47-63Hz |
| Short Circuit |
Shut down o/p voltage;
Repower on to recover after fault condition is removed
|
| Over Loading | 120% |
| Efficiency | 86% |
| Withstand Voltage | I/P-O/P: 1880V AC |
| Isolation Resistance | I/P-O/P: 100MΩ / 500V DC / +25ºC / 70% RH |
| Operating Temperature | -40ºC ~ +60ºC |
| Warranty | 5 Years |
| UL Listed | UL, FCC |
| Case Quantities | 10 |
