The smart thermostat - Zigbee (OTH3600-GA-ZB) is compatible with the GT130 smart gateway. Among other features, it can be programmed (only through the Neviweb® platform) to allow individual temperatures to be set for six periods per day and for each day of the week. Daily and monthly usage can be monitored to help cut down on heating costs.
The thermostat has integral ground fault protection (Class A – GFCI), which can detect 5 mA of current leakage, and is equipped with a terminal for connecting a floor temperature sensor. There is also a built-in ambient sensor which provides room temperature control and the ability to set a maximum/minimum floor temperature.
The OTH3600-GA-ZB also features an auxiliary contact that can be used to control additional heat sources, either by using a slave module for heated floors (TR1310 Series) or a relay and low-voltage transformer for electric heaters.
| Product Family | Smart Thermostat - Zigbee for Floor Heating System |
| Type | Programmable, electronic, double-pole, 4-wire smart thermostat for floor heating system. |
| Color | Standard: white |
| Voltage | 120/208/240V, 50/60Hz |
| Rating | 15A at 120/208/240V |
| Control |
• 15-minute cycle. • Resolution and precision: ± 0.5 °C (1 °F). • Auxiliary contact offers the possibility of controlling supplemental heat sources to be added by either using a slave module (TR1310-120-240GA) for heated floors or using a low voltage relay and a low voltage transformer for an electric heater. |
| Temperature control mode |
• A mode: Ambient temperature control and possibility of limiting the temperature of the floor using an external temperature sensor. • F mode: Floor temperature control using and external temperature sensor and possibility of limiting the ambient temperature. |
| Temperature range |
• Floor: 5 °C (40 °F) to 36 °C (96 °F). • Ambient: 5 °C (40 °F) to 36 °C (96 °F) |
| Display |
• Digital display of actual and setpoint temperature (°C or °F), heating level, actual mode and clock (12 or 24-hour format). • Outside temperature display. • Temperature setpoint and settings are permanently recorded. • GFCI fault indicator (ground fault circuit interrupter). • Black backlit. |
| Program |
• Programming features are accessible only through the Neviweb app. • The connectivity requires a GT130 smart gateway |
| Installation | 4-wire thermostat with ambient sensor and floor sensor |
| Warranty | 3-year warranty against defects. |
