Philips

Philips XH095C275V054BSF1, Advance LED Electronic Driver, 95W 0.1-2.75A 20-54VDC via SimpleSet, 0-10V Dimming, 347-480VAC Input

In stock
SKU: XH095C275V054BSF1
$79.99
Rated voltage
Power

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Advance Xitanium outdoor LED drivers with SimpleSet technology are designed to give OEMs ultimate flexibility. The drivers' wide operating windows and simple programming make it easy for luminaire manufacturers to design luminaires of different sizes and lumen levels for outdoor applications.
Stock Code XH095C275V054BSF1
Family Advance Xitanium LED Driver with SimpleSet
Part No XH095C275V054BSF1M
Dimmable Yes
Length 9.45 inch / 240 mm
Width 2.31 inch / 58 mm
Height 1.48 inch / 37.6 mm
Input Voltage 347 - 480 Vac
Bulb Type LED
Operates AOC (Adjustable Output Current) 0.1A-2.75A via SimpleSet (Factory Default at 2.3A)
Output Voltage 20-54VDC
Output Current 0.1 - 2.75A
Output Power 95W
Power Factor >0.9
Start Temperature  -40°C~55°C
Weight  2.1 Lbs / 0.95 kgs
UL Listed cULus, For Dry and Damp Location
