Home » Philips XH100C110V143BSY1, Advance Xitanium LED Electronic Driver, 100W 0.1-1.1A 48-143VDC Output, 0-10V Dimming with SimpleSet, 347-480VAC Input
Philips

Philips XH100C110V143BSY1, Advance Xitanium LED Electronic Driver, 100W 0.1-1.1A 48-143VDC Output, 0-10V Dimming with SimpleSet, 347-480VAC Input

In stock
SKU: XH100C110V143BSY1
$85.99
Rated voltage
Power

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Stock Code XH100C110V143BSY1
Family Advance Xitanium LED Driver with SimpleSet
Part No XH100C110V143BSY1M
Dimmable Yes
Length 6.59 in / 167.5 mm
Width 2.32 inch / 58.8 mm
Height 1.48 inch / 37.6 mm
Input Voltage 347 - 480 Vac
Output
Voltage: 48-143VDC
Current: 0.1 - 1.1A
Power:   100W
Bulb Type LED
Power Factor >0.95
Start Temperature ‐40°C~55°C
UL Listed cULus, CSA, cETLus, For Dry and Damp Location
Weight 1.44 Lbs / 0.65 kgs
