Home » Philips XI013C050V054BSM2, Xitanium Led Driver, 13W 0.1-0.5A 10-54Vdc Class 2 Output, 0-10V Dimming with SimpleSet, 120-277Vac Input, Bottom Entry
Philips

Philips XI013C050V054BSM2, Xitanium Led Driver, 13W 0.1-0.5A 10-54Vdc Class 2 Output, 0-10V Dimming with SimpleSet, 120-277Vac Input, Bottom Entry

In stock
SKU: XI013C050V054BSM2
$49.99
Rated voltage
Power

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Stock Code XI013C050V054BSM2
Family Xitanium Constant Current AC/DC Driver
Dimmable Yes
Length 4.98 in / 126.6 mm
Width 2.36 in / 59.9 mm
Height 0.98 in / 24.9 mm
Input Voltage 120-277Vac
Bulb Type LED
Mounting Panel Mount with Bottom Entry Leads
Output Voltage 10-54VDC
Output Current 0.1 - 0.56A
Output Power 13W
Power Factor >0.9
Weight  0.44 Lbs / 0.2 kgs
UL Listed cULus, For Dry and Damp Location
Operates Factory default output current is 0.5A, AOC (Adjustable Output Current): 0.1A-0.5A via SimpleSet programming (refer to graph and notes below)
