Philips XI100C150V038CNH1, Advance Xitanium LED Driver, 100W Max. 54W per Channel 20-36VDC 1.5A Outpu, 0-10V Dimming, 120-277VAC Input
Regular price
$108.80
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Stock Code | XI100C150V038CNH1 |
| Family | Philips Advance Xitanium |
| Part No | XI100C150V038CNH1M |
| Dimmable | Yes |
| Length | 5.7 in |
| Width | 3.6 in |
| Height | 1.5 in |
| Input Voltage | 120-277VAC, 50/60Hz |
| Input Current |
1A@120VAC, 0.4A@277VAC
|
| Output |
Voltage: 20-36V
Current: 1.50A
Power: 100W Max
|
| Bulb Type | LED |
| Power Factor | >0.95 |
| Start Temperature | ‐40°C (-40°F)~55°C (131°F) |
| THD | <15% |
| Mounting Length | 6.00 in (151.5 mm) |
| UL Listed | UL8750, UL1310, UL935, CSA-C22.2 No. 250.13-12, CSA C22.2 No. 223 |
| Weight | 2.1 Lbs / 0.95 kgs |
