Philips Xitanium XI180C090V285VSF2, 180W Output - 0.1-0.9A Output Current, 100-285VDC Output Voltage, 120-277VAC Input, DALI Dimming Led Driver with Auxiliary Power Output
Regular price
$129.99
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The Advance Xitanium Sensor Ready (SR) LED driver can help reduce complexity and cost of light fixtures used in connected lighting systems in outdoor lighting applications. It's D4i certified and features a standard-compliant digital interface to enable direct connection to compatible networked lighting control (NLC) solutions. Functionality that ordinarily would require additional auxiliary components is integrated into the driver. The result is a simple, cost-effective light fixture that can enable every fixture to become a wireless node.
| Stock Code | XI180C090V285VSF2 |
| Family | Philips Advance Xitanium Constant Current Led Driver |
| Part No | XI180C090V285VSF2M |
| Dimmable | Yes |
| Length | 8.31 inch / 211.1 mm |
| Width | 2.31 inch / 58 mm |
| Height | 1.48 inch / 37.6 mm |
| Input Voltage | 120-277V, 50/60Hz |
| Input Current | 1.76A@120V, 0.76A@277V |
| Output |
Voltage: 100-285VDC
Current: 0.1 - 0.9A
Power: 180W
|
| Bulb Type | LED |
| Power Factor | >0.95 |
| Start Temperature | ‐40°C ~55°C |
| Mounting Length | 8.91inch |
| Weight | 2.1 Lbs |
| UL Listed | UL, CSA |
| Notes | AOC (adjustable output current) 0.1A-0.9A via SimpleSet (Factory Default at 0.7A) |
