Philips XJ180C180V144VSF2, Advance Xitanium SR LED Driver, 180W 0.1-1.8A 50-144VDC Output, DALI Dimming, 277-480VAC Input
Regular price
$137.60
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Stock Code | XJ180C180V144VSF2 |
| Family | Advance Xitanium SR LED Driver |
| Part No | XJ180C180V144VSF2M |
| Dimmable | Yes |
| Length | 8.31 inch / 211.1 mm |
| Width | 2.31 inch / 58 mm |
| Height | 1.48 inch / 37.6 mm |
| Input Voltage | 277 - 480 VAC |
| Output |
Voltage: 100-285VDC
Current: 0.1A-1.8A via SimpleSet (Factory Default at 1.5A)
Power: 180W
|
| Bulb Type | LED |
| Power Factor | >0.95 |
| Start Temperature | ‐40°C~55°C |
| UL Listed | UL 8750, CSA 250.13, Class P (UL, CSA, ETL), For Dry and Damp Location |
| Weight | 2.1 Lbs / 0.95 kgs |
