Rotom M4-R2723, 5'' Condenser Fan Replacement Motor, PSC Type, Ball Bearing, 1/4,1/5,1/6 HP, 208/230 Volts, 2/1.2/1 Amps, 1075/1145/1165 RPM, Reversible Rotation, 1/2''x3'' Shaft
Regular price
$378.40
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Included: Durable collar studs with 5/8” extension, 8-32 threads; Extra mounting nuts with locking feature; Easy-to-install plugs; Mounting instructions with easy-to-read diagrams
- Multi-Mounting System
- Single speed multi-horsepower replacement motor uses one simple connection
- Easy-to-read connection diagram attached to white lead wire
- Water-resistant reversing plug
- Double sealed ball bearings for dependable long life
- Rubber shaft slinger keeps water and dirt out of motor
- Water-resistant rubber grommet at lead opening
- 60°C max ambient
- Class B insulation
- Lead length 36”
- Continuous duty, air over
| Type |
Permanent Split Capacitor (PSC)
|
| Horsepower |
1/4, 1/5, 1/6
|
| Revolutions Per Minute | 1075, 1145, 1165 |
| Voltage | 208/230 |
| Amps | 2.0, 1.2, 1.0 |
| Speed | One |
| Rotation | Reversible |
| Enclosure |
Totally Enclosed
|
| Capacitor | 7.5 / 370V |
| Diameter | 5.0'' |
| Body Length | 4.5'' |
| Frame Size | 42 |
| Shaft Size | 1/2'' × 3'' |
| Bearing | Ball |
