Thomas Research LED30W-85-C0350, Output 30W 350mA 28-85Vdc, Input 90-305Vac, Constant Current LED Driver, IP66
Regular price
$109.24
⚠️ IMPORT NOTICE
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
FOR ALL ORDERS OUTSIDE CANADA, CUSTOMERS ARE RESPONSIBLE FOR ANY IMPORT DUTIES, TARIFFS, TAXES, AND CUSTOMS FEES THAT MAY APPLY TO THEIR ORDERS.
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Stock Code | LED30W-85-C0350 |
| Family | LED-30W Series Fixed Output and Dimmable Switch Mode LED Drivers |
| Length | 5.31 in (135mm) |
| Width | 1.65 in (42mm) |
| Height | 0.83 in (21mm) |
| Input Voltage | 90 - 305 Vac |
| Input Current | 0.41 A max |
| Bulb Type | LED |
| IP Rating | IP66 |
| Output Voltage | 28-85Vdc |
| Output Current | 350mA |
| Output Power | 30W |
| Power Factor | >0.95 |
| THD | <20% |
| Lead Lengths | Black/White 6" 18AWG, Red(+)/Blue(-) 6" 20AWG |
| UL Listed | cRUus, FCC, CE, RoHs |
| Warranty | 5 Years |
